Specification |
System |
Controller Chip Processor |
Dual-core 32-bit DSP (XM650V200), pure hard compression, Watchdog |
Image Sensor |
1/3-inch low-light CMOS sensor |
Operating system |
Embedded LINUX operating system |
Image encoding format |
Smart H.265X |
APP |
Super Look(support andriod and IOS) |
Video |
Effective video pixel |
3MP |
Resolution |
Main stream: 2304*1296@12fps; Sub stream: 800*448@12fps |
Minimum Illumination |
Color: 0.01Lux@(F1.2,AGC ON);0 Lux with IR. |
B/W: 0.001Lux@(F1.2,AGC ON);0 Lux with IR. |
Lens |
3.6mm (standard) |
Viewing Angle |
92° |
Video Flip |
Up/Down/Left/Right Flip |
Screen |
Display Size |
2.4-inch IPS HDTV screen |
Resolution |
320*240 |
Night Vision |
Night Vision Light Control Mode |
IR |
Number of fill light |
6pcs |
Platform |
Controls |
Swivel Angle Horizontal:355°;Vertical:90° |
Flip |
Flip up/down/left/right |
Audio |
Coding Standard |
G.711 |
pick up (a sound) |
Yes |
Speaker |
Yes |
Video |
Video file size |
≈6G/天 |
Recording mode |
Manual, dynamic detection, timer, alarm |
Video storage |
TF card/Cloud |
Storage |
Cloud storage + TF local video (max.:128GB) |
Remote playback |
Yes |
Photo capture |
Yes |
Alarm |
Humanoid detection |
Yes |
Regional alert |
Yes |
Alarm message |
Yes |
Network |
Wireless network |
2.4G WIFI 802.11b/g/n |
Networking |
Bluetooth Fast Networking |
Extension |
Reset |
Yes |
Business |
Support two-way video intercom, cell phone client remote monitoring and alarming |
Humanoid tracking |
Yes |
360 degree positioning |
Yes |
Power Supply |
Power Supply |
DC 5V 1A |
Power Supply Interface |
Type-C |
Environment |
Applicable places |
Families, stores, supermarkets, factories and other places |
Installation |
Wall-mounted, flat |
Operating temperature |
-20℃-+55℃ |
Working Humidity |
10%-90% |
